A24 ; General Television (ID = 2652726) Radio
General Television: A24 [Radio] ID = 2652726 800x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model A24, General Television and Radio Corp.; Chicago, IL:
Eigene Bild. Frontansicht A24 mit Holzgehäuse

Country:  United States of America (USA)
Manufacturer / Brand:  General Television and Radio Corp.; Chicago, IL
Brand

General
Year: 1940 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12A8 12K7 12Q7 50L6 35Z5
schematic requested
Main principle Superheterodyne (common)
Wave bands Broadcast only (MW).
Details
Power type and voltage AC/DC-set / 105-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: A24 - General Television and Radio
Material Wooden case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 230 x 160 x 90 mm / 9.1 x 6.3 x 3.5 inch
Notes

Power cable has four wires, one of which is the antenna.









Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)

Model page created by Heinrich Stummer. See "Data change" for further contributors.
