21C1449 M3 Line
General Electric Co. (GE); Bridgeport CT, Syracuse NY
- Country
- United States of America (USA)
- Manufacturer / Brand
- General Electric Co. (GE); Bridgeport CT, Syracuse NY
- Year
- 1957 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 318900
-
- Brand: Musaphonic
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 16
- Valves / Tubes
- 2AF4A 2CY5 5CL8 3AU6 3AU6 3CB6 8CX8 3AU6 5T8 12C5 6CM7 6CG7 12DQ6 12AX4GTA 1X2A 21CZP4
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: 21C1449 M3 Line - General Electric Co. GE;
- Shape
- Tablemodel, with any shape - general.
- Notes
-
General Electric model 21C1449 is a 17" b/w TV with US standard VHF tuner channels 2 thru 13, and 14 thru 83 UHF. Equipped with chassis VHF- tuner RJX-101, UHF- tuner RUX-023 and picture tube 21CZP4.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 383 Folder 3 dated 1-58.)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
