- Country
- United States of America (USA)
- Manufacturer / Brand
- General Electric Co. (GE); Bridgeport CT, Syracuse NY
- Year
- 1953 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 361130
-
- Brand: Musaphonic
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 23
- Valves / Tubes
- 6AB4 6AK5 12AT7 6CB6 6CB6 6CB6 12BH7 6CB6 6AU6 6T8 6AQ5 12AT7 12AX7 12BH7 6BX7GT 12AU7 12AU7 25BQ6GT or 25AV5 6V3 1X2A 1X2A 1X2A 21EP4A
- Main principle
- Superhet with RF-stage
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Material
- Metal case
- from Radiomuseum.org
- Model: 21C202 - General Electric Co. GE;
- Shape
- Tablemodel, with any shape - general.
- Notes
-
General Electric model 21C202 is a 21” b/w TV with US standard VHF tuner channels 2 thru 13. Equipped with VHF tuner RJX-049 and picture tube 21EP4A.
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 194, folder 2, dated 2-53)
- Author
- Model page created by Dirk Taekels. See "Data change" for further contributors.
