Musaphonic 221 ; General Electric Co. (ID = 2300594) Radio
General Electric Co.: Musaphonic 221 [Radio] ID = 2300594 1400x1104
Select picture or schematic to display from thumbnails on the right and click for download.
For model Musaphonic 221, General Electric Co. (GE); Bridgeport CT, Syracuse NY:
GE 221 Top View after restoration

Country:  United States of America (USA)
Manufacturer / Brand:  General Electric Co. (GE); Bridgeport CT, Syracuse NY
Brand

Musaphonic
Year: 1946/1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12SK7 12SA7 12SG7 12SQ7 35L6GT 35Z5GT
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.25 inch = 13.3 cm
Power out 1.25 W (unknown quality)
from Radiomuseum.org Model: Musaphonic 221 - General Electric Co. GE;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 340 x 220 x 220 mm / 13.4 x 8.7 x 8.7 inch
Notes

Built in loop antenna for BC.

Net weight (2.2 lb = 1 kg) 5.3 kg / 11 lb 10.8 oz (11.674 lb)
Collectors' prices
External source of data Ernst Erb
Source of data Collector's Guide to Antique Radios 4. Edition
Circuit diagram reference Rider's Perpetual, Volume 15 = 1947 and before
Mentioned in The Radio Collector's Directory and Price Guide 1921 - 1965
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 4, Folder 464-1)
Literature/Schematics (2) Radio Retailing (Radio & Television R.) (April 1946 page 34.)
Literature/Schematics (3) General Electric Folder 1000M-PUB.NO. 175-59 for 1947.
