HE-74L ; General Electric Co. (ID = 575231) Radio
General Electric Co.: HE-74L [Radio] ID = 575231 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model HE-74L, General Electric Co. (GE); Bridgeport CT, Syracuse NY

Country:  United States of America (USA)
Manufacturer / Brand:  General Electric Co. (GE); Bridgeport CT, Syracuse NY
Brand

Musaphonic
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: 6SK7 6K8 6SK7 6SQ7 6U5 6Y6G 5Y3G
Main principle Superhet with RF-stage; ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 103-117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out 3.5 W (unknown quality)
from Radiomuseum.org Model: HE-74L - General Electric Co. GE;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 20.3 x 12.3 x 9.3 inch / 516 x 312 x 236 mm
Notes Electron tuning indicator.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 12 = ca. 1941 and before
Literature/Schematics (1) General Electric Radio Service Notes 1939-1942
