• Year
  • 1940
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 42319
    • Brand: Musaphonic

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 13
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Wave bands
  • Broadcast, 2 Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 115 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
  • Power out
  • 15 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: HM-136 - General Electric Co. GE;
  • Shape
  • Console with Push Buttons.
  • Dimensions (WHD)
  • 32.2 x 40 x 13.7 mm / 1.3 x 1.6 x 0.5 inch
  • Notes
  • Plug-in type terminal for connecting rec. player or television sound channel.
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 11 = ca. 1940 and before
  • Literature/Schematics (1)
  • General Electric Radio Service Notes 1939-1942
