- Country
- United States of America (USA)
- Manufacturer / Brand
- General Electric Co. (GE); Bridgeport CT, Syracuse NY
- Year
- 1963 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 237330
-
- Brand: Musaphonic
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 0
- Number of Transistors
- 6
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 455/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 50 to 60 cycles, 105 to 120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: T225A - General Electric Co. GE;
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Notes
-
The GE T225A, T235A, and T236A AM/FM similar models have the following features:
Model AFC Color T225A No Nutmeg T235A Yes Nutmeg T236A Yes Honey Beige
- Literature/Schematics (1)
- Photofact Folder, Howard W. SAMS (Set 686, folder 10, date 4/64)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
