Combination Record-Changer Recorder GI-RC130L

General Industries Co., The; Elyria, OH

Data
Forum
Pictures
Collections

  • Year
  • 1948/1949 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 183572

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Details
  • Recording phonogr.-Disc Recorder
  • Power type and voltage
  • 115 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Combination Record-Changer Recorder GI-RC130L - General Industries Co., The;
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 14 x 8.1 x 14 inch / 356 x 206 x 356 mm
  • Notes

  • Record changer for 10" and 12" records, with cutting arm to make home recordings on records up to 10".

    Playback cartridge: Astatic L-70 or L-40
    Cutting crystal: Astatic X-26 or equivalent

    Magnetic cutter M41-10 at $2 extra.

  • Price in first year of sale
  • 69.75 $
  • Circuit diagram reference
  • Rider's Perpetual, Volume 17 = 1948 and before
  • Mentioned in
  • Radio's Master Catalog, 12th Edition 1949, p. E-29
