Week-End (?)
Général-Radio; Dijon
- Country
- France
- Manufacturer / Brand
- Général-Radio; Dijon
- Year
- 1955 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 279094
-
- alternative name: General-Radio
Vue du cadran
- Number of Tubes
- 5
- Number of Transistors
- Semiconductors
- E125C130
- Main principle
- Superhet with RF-stage; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Line / Batteries (any type) / AC/DC 120 / 2 x 4.5 & 90 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Week-End - Général-Radio; Dijon
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 300 x 210 x 120 mm / 11.8 x 8.3 x 4.7 inch
- Notes
-
Le nom du modèle n'est pas certain. Voir aussi modèle Week-End d'année 1957.
Nombreux modèles identiques ou comparables existe chez d'autres marques : Clarson Mistral, Lemouzy PS65, Radio-LL Super Rallye 55, Socradel Week-End 55.
- Net weight (2.2 lb = 1 kg)
- 3.5 kg / 7 lb 11.3 oz (7.709 lb)
- Author
- Model page created by Philippe Harang. See "Data change" for further contributors.
