• Country
• Canada

• Manufacturer / Brand
• Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON

• Year
• 1962 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 209513

• Number of Tubes
• 6

• Valves / Tubes
• 12BE6 12BA6 19JN8 19HV8 35W4 35C5

• Main principle
• Superheterodyne (common); none

• Tuned circuits
• 6 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• AC/DC-set / 115 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Power out
• 1.5 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: AM/FM Mantle Radio 11R31 - Canadian General Electric

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 13 x 7 x 5.5 inch / 330 x 178 x 140 mm

• Notes
• Manufactured by Canadian General Electric Co. Toronto Canada

• Author
• Model page created by Neil Van Dusen. See "Data change" for further contributors.
