Unknown ; Giannini, Santiago (ID = 1793962) Radio
Giannini, Santiago: Unknown [Radio] ID = 1793962 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Unknown (2), Giannini, Santiago Chile:
Grill cloth is not original, lack bezel for the magic eye.

Country:  Chile
Manufacturer / Brand:  Giannini, Santiago Chile
Year: 1967 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12BE6 12BA6 12AV6 50C5 12Z-E8 35W4
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 2 W (undistorted)
from Radiomuseum.org Model: Unknown - Giannini, Santiago Chile
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 420 x 260 x 200 mm / 16.5 x 10.2 x 7.9 inch
Notes

Receptor superheterodino con bandas de onda media y onda corta de 19-49m.
Incorpora el tubo indicador de sintonía 12Z-E8, de diseño y fabricación japonesa.

It is currently not known whether the magic eye was retrofitted or built-in originally.
See model Unknown (1) without magic eye 12Z-E8 and slightly different shape.

Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)

Model page created by Víctor Caselli-Diaconescu. See "Data change" for further contributors.
