For model GN-1, Gilfillan Bros.Inc.; Los Angeles (CA):
Front view of an unrestored Gilfillan model GN1. Photograph from David Woodill.
Country:  United States of America (USA)
Manufacturer / Brand:  Gilfillan Bros.Inc.; Los Angeles (CA)
Year: 1924 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5:
Main principle TRF without regeneration; 2 AF stage(s); Neutrodyne
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast only (MW).
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Model: GN-1 - Gilfillan Bros.Inc.; Los
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).

The Gilfillan model GN-1 has three dials (primary tuning control knobs) plus two knobs for "power control" and a meter behind another door (right). The other small door on the left is for log charts and owner manual.

Price in first year of sale 175.00 $
External source of data Ernst Erb
Source of data Radio Collector`s Guide 1921-1932
Mentioned in Collector's Guide to Antique Radios 4. Edition
