2 Band Eight Transistor Radio GR-822

Global Mfg. Co.; Tokyo

  • Year
  • 1964 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 289104

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 8
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 5 AM circuit(s)
  • Wave bands
  • Broadcast and Short Wave (SW).
  • Power type and voltage
  • Dry Batteries / 1 x 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: 2 Band Eight Transistor Radio GR-822 - Global Mfg. Co.; Tokyo
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 200 x 75 x 40 mm / 7.9 x 3 x 1.6 inch
  • Notes
  • SW: 3.9...11.5 MHz

  • Net weight (2.2 lb = 1 kg)
  • 0.650 kg / 1 lb 6.9 oz (1.432 lb)
  • Author
  • Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
