• Year
  • 1961 ?
  • Category
  • Citizen Band Equipment
  • Radiomuseum.org ID
  • 140387

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 10
  • Main principle
  • Superheterodyne (common); ZF/IF 1680 kHz
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / 117 / 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
  • from Radiomuseum.org
  • Model: CB-100 - World Radio Laboratories WRL,
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Notes
  • Any 3 of CB Channels 1 thru 22
  • Author
  • Model page created by Heribert Jung. See "Data change" for further contributors.
