Citizens Broadcaster CB-100A

Citizens Broadcaster CB-100A; World Radio (ID = 554501) Citizen

Citizens Broadcaster CB-100A; World Radio (ID = 554502) Citizen

Citizens Broadcaster CB-100A; World Radio (ID = 554503) Citizen

Citizens Broadcaster CB-100A; World Radio (ID = 554504) Citizen

Citizens Broadcaster CB-100A; World Radio (ID = 554505) Citizen

Citizens Broadcaster CB-100A; World Radio (ID = 554506) Citizen

Citizens Broadcaster CB-100A; World Radio (ID = 554507) Citizen

Citizens Broadcaster CB-100A; World Radio (ID = 554508) Citizen
Citizens Broadcaster CB-100A; World Radio (ID = 553890) Citizen
Use red slider bar for more.
Citizens Broadcaster CB-100A; World Radio (ID = 553890) Citizen
World Radio: Citizens Broadcaster CB-100A [Citizen] ID = 553890 933x484
Select picture or schematic to display from thumbnails on the right and click for download.
For model Citizens Broadcaster CB-100A, World Radio Laboratories (WRL), (Globe Electronics); Council Bluffs, IA:
CB-Photofact Vol.3 Page 49

Country:  United States of America (USA)
Manufacturer / Brand:  World Radio Laboratories (WRL), (Globe Electronics); Council Bluffs, IA
Year: 1962 ? Category: Citizen Band Equipment
Valves / Tubes 10: 12BA6 6U8 12BA6 12BA6 6BJ8 12AZ7 12AQ5 6C4 12AQ5 12BW4
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Short Wave (SW only)
Details
Power type and voltage Line / Storage batteries (perhaps also batteries) / 110-120 / 6; 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 2.5 inch = 6.4 cm
Power out
from Radiomuseum.org Model: Citizens Broadcaster CB-100A - World Radio Laboratories WRL,
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Notes Any 3 of CB Channels 1 thru 23.
Circuit diagram reference Photofact Folder, Howard W. SAMS

Model page created by Heribert Jung. See "Data change" for further contributors.



All listed radios etc. from World Radio Laboratories (WRL), (Globe Electronics); Council Bluffs, IA
Here you find 28 models, 24 with images and 19 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
