Echo 485

Echo 485; GMR G.M.R., Georg, (ID = 645781) Radio

Echo 485; GMR G.M.R., Georg, (ID = 1413253) Radio

Echo 485; GMR G.M.R., Georg, (ID = 1417481) Radio
Echo 485; GMR G.M.R., Georg, (ID = 645556) Radio Echo 485; GMR G.M.R., Georg, (ID = 645557) Radio
Echo 485; GMR G.M.R., Georg, (ID = 645562) Radio Echo 485; GMR G.M.R., Georg, (ID = 1417057) Radio
Echo 485; GMR G.M.R., Georg, (ID = 1417058) Radio
Use red slider bar for more.
Echo 485; GMR G.M.R., Georg, (ID = 645556) Radio
GMR G.M.R., Georg,: Echo 485 [Radio] ID = 645556 630x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Echo 485, GMR (G.M.R.), Georg, Montastier et Rouge; Montrouge, Paris

Country:  France
Manufacturer / Brand:  GMR (G.M.R.), Georg, Montastier et Rouge; Montrouge, Paris
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 58 2A7 2B7 47 80
Main principle Superhet with RF-stage; ZF/IF 125 kHz; Reflex
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 115; 130; 200; 230 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 18 cm = 7.1 inch
Power out 2.7 W (unknown quality)
from Radiomuseum.org Model: Echo 485 - GMR G.M.R., Georg, Montastier
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 370 x 425 x 210 mm / 14.6 x 16.7 x 8.3 inch
Price in first year of sale 1'375.00 FRF
Mentioned in -- Original prospect or advert (Dépliant GMR 1934-1935)

Model page created by Claude Weeber † 27.5.2010. See "Data change" for further contributors.



All listed radios etc. from GMR (G.M.R.), Georg, Montastier et Rouge; Montrouge, Paris
Here you find 119 models, 85 with images and 30 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
