RC4; GMR G.M.R., Georg, (ID = 2567021) Radio
GMR G.M.R., Georg,: RC4 [Radio] ID = 2567021 1400x807
Select picture or schematic to display from thumbnails on the right and click for download.
For model RC4, GMR (G.M.R.), Georg, Montastier et Rouge; Montrouge, Paris

Country:  France
Manufacturer / Brand:  GMR (G.M.R.), Georg, Montastier et Rouge; Montrouge, Paris
Year: 1924 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: N_Tela N_Tela N_Tela N_Tela
Main principle TRF with regeneration
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 4 & 80 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: RC4 - GMR G.M.R., Georg, Montastier
Material Wooden case, TUBES VISIBLE.
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 480 x 170 x 225 mm / 18.9 x 6.7 x 8.9 inch
Notes

Toutes ondes de 150 à 2000 m.

Ce modèle a aussi été commercialisé sous la marque Téla.

L'année 1922 specifié dans TSF Antique est très probablement eronnée.

Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Mentioned in TSF Antique 1921 à 1927 (page 63)
Literature/Schematics (1) -- Original prospect or advert
Literature/Schematics (2) Le Guide du Collectionneur TSF Biraud/Foster, Vol. I (page 179)

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
