• Year
  • 1975
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 98551

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / R14: 1,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Unigor A43 - Goerz Electro Ges.m.b.H., Wien
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 212 x 110 x 82 mm / 8.3 x 4.3 x 3.2 inch
  • Notes
  • Vielfachmessinstrument
    Messbereich V AC/DC: 100 mV bis 1000 V
    Messbereich A AC/DC: 10 µA bis 10 A
    Ohmbereich: 0,2 Ohm - 50 MOhm
    Kapazitätsbereich: 1 nF bis 10 µF
    dB Messungen möglich
    Innenwiderstand: 100 kOhm/V.

  • Price in first year of sale
  • 577.00 DM
  • Mentioned in
  • (A) Radio Elektronik Schau; Heft 11, 1975 Werbeschaltung
  • Author
  • Model page created by Egon Penker. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Unigor is part of the collections of the following members.

 Forum

Forum contributions about this model: Goerz Electro Ges.m.: Unigor A43

Threads: 1 | Posts: 1

Dieses Instrument habe ich sehr geschätzt bei der Entwicklungsarbeit.

Es hat 100 kOhm/V belastet also das Messobjekt gering.

Es ist noch völlig passiv, wird also vom Messobjekt wenig beeinflußt. Ein aktives Instrument kann z.B. in Oszillatorschaltungen falsche Ergebnisse liefern.

Ich habe 2 Stück, alle sehr gepflegt.

Das Gerät 03RL673 habe ich noch mit dem Goerz Universal 4 mit nur 50 kOhm/v entwickelt, das auch im RM zu finden ist. Leider habe ich das nicht kaufen können. Das war in den 60ern noch nicht üblich.

Rudolf Drabek, 21.Mar.13
