Flirt 302

Flirt 302; Graetz, Altena (ID = 285577) Radio

Flirt 302; Graetz, Altena (ID = 1875058) Radio
Flirt 302; Graetz, Altena (ID = 285579) Radio Flirt 302; Graetz, Altena (ID = 1034953) Radio
Flirt 302; Graetz, Altena (ID = 1034954) Radio Flirt 302; Graetz, Altena (ID = 1034955) Radio
Flirt 302; Graetz, Altena (ID = 1034957) Radio Flirt 302; Graetz, Altena (ID = 1034959) Radio
Flirt 302; Graetz, Altena (ID = 1034960) Radio Flirt 302; Graetz, Altena (ID = 1034962) Radio
Flirt 302; Graetz, Altena (ID = 2258346) Radio Flirt 302; Graetz, Altena (ID = 2258347) Radio
Use red slider bar for more.
Flirt 302; Graetz, Altena (ID = 285579) Radio
Graetz, Altena: Flirt 302 [Radio] ID = 285579 933x528
Select picture or schematic to display from thumbnails on the right and click for download.
For model Flirt 302, Graetz, Altena (Westfalen)

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1971–1973 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 6 cm = 2.4 inch
Power out 0.12 W (unknown quality)
from Radiomuseum.org Model: Flirt 302 - Graetz, Altena Westfalen
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 92 x 95 x 33 mm / 3.6 x 3.7 x 1.3 inch
Notes Gehäuse in schwarz, gelb oder orange. Festsendertaste für Lieblingssender im Bereich 1-1,6 MHz, über zweiten Doppeldrehko auf der Rückseite einstellbar.
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
External source of data Erb
Source of data Handbuch VDRG 1971/1972
