UHF-Konverter FK61

UHF-Konverter FK61; Graetz, Altena (ID = 238117) Converter
UHF-Konverter FK61; Graetz, Altena (ID = 1465230) Converter UHF-Konverter FK61; Graetz, Altena (ID = 51617) Converter
UHF-Konverter FK61; Graetz, Altena (ID = 51620) Converter UHF-Konverter FK61; Graetz, Altena (ID = 956404) Converter
UHF-Konverter FK61; Graetz, Altena (ID = 51619) Converter UHF-Konverter FK61; Graetz, Altena (ID = 51618) Converter
UHF-Konverter FK61; Graetz, Altena (ID = 956405) Converter UHF-Konverter FK61; Graetz, Altena (ID = 1465231) Converter
UHF-Konverter FK61; Graetz, Altena (ID = 1465232) Converter UHF-Konverter FK61; Graetz, Altena (ID = 1465233) Converter
Use red slider bar for more.
UHF-Konverter FK61; Graetz, Altena (ID = 1465230) Converter
Graetz, Altena: UHF-Konverter FK61 [Converter] ID = 1465230 933x457
Select picture or schematic to display from thumbnails on the right and click for download.
For model UHF-Konverter FK61, Graetz, Altena (Westfalen)

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1961/1962 Category: Pre-stage (adaptor for SW/FM/VHF/UHF incl. built-in), Frequency converter
Valves / Tubes 2: EC88 EC86
Semiconductors (the count is only for transistors) B250C75
Main principle RF Converter/Adapter (not voltage converter); ZF/IF 65000 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: UHF-Konverter FK61 - Graetz, Altena Westfalen
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 215 x 70 x 170 mm / 8.5 x 2.8 x 6.7 inch
Notes UHF-Konverter für die Bereiche VI/V; setzt auf VHF Kanal 4 (~65 MHz) um. "Set-Top-Box" für ältere nur VHF-Fernseher. Gehäuse verschiedenfarbig. Netzsteckdose für Fernsehgerät, Bimetall-Einschaltautomatik.
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Price in first year of sale 158.00 DM
External source of data Eilert Menke
Source of data HdB d.Rdf-& Ferns-GrH 1961/62
Mentioned in - - Manufacturers Literature (Graetz Nachrichten Nummer 40, 15.03.1961)

Model page created by a member from D. See "Data change" for further contributors.
