Page netzautomatic 302; Graetz, Altena (ID = 1659569) Radio
Graetz, Altena: Page netzautomatic 302 [Radio] ID = 1659569 900x559
Select picture or schematic to display from thumbnails on the right and click for download.
For model Page netzautomatic 302, Graetz, Altena (Westfalen)

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1971/1972 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220 / 6×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1.3 W (unknown quality)
from Radiomuseum.org Model: Page netzautomatic 302 - Graetz, Altena Westfalen
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 325 x 245 x 75 mm / 12.8 x 9.6 x 3 inch
Notes Gespreiztes 49-m-Band.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Price in first year of sale 189.00 DM
External source of data Erb
Source of data Handbuch VDRG 1971/1972


All listed radios etc. from Graetz, Altena (Westfalen)
Here you find 756 models, 670 with images and 583 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
