PAGINO netzautomatic 304; Graetz, Altena (ID = 2490030) Radio
Graetz, Altena: PAGINO netzautomatic 304 [Radio] ID = 2490030 1400x956
Select picture or schematic to display from thumbnails on the right and click for download.
For model PAGINO netzautomatic 304, Graetz, Altena (Westfalen)

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1973–1975 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 5 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220-240 / 6×1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.6 W (unknown quality)
from Radiomuseum.org Model: PAGINO netzautomatic 304 - Graetz, Altena Westfalen
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 250 x 135 x 60 mm / 9.8 x 5.3 x 2.4 inch
Notes Nichtabschaltbare UKW-Scharfabstimmung.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
External source of data Erb
Source of data Katalog RFP 1973
