For model Regatta 44H, Graetz, Altena (Westfalen):
ebay: franxpost #6553275557

Country:  Germany
Manufacturer / Brand:  Graetz, Altena (Westfalen)
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 9: AF134 AF125 SN695-16 or. AF125 SN695-16 or. AF125 SN695-16 or. AF125 BC108 BC108 AC175 AC117 AA112
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / (5 × 1,5) Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Regatta 44H - Graetz, Altena Westfalen
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 150 x 75 mm / 10.2 x 5.9 x 3 inch
Notes

Netzbetrieb mit zusätzlichem Netzteil möglich.

Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Source of data Handbuch VDRG 1967/1968 / Radiokatalog Band 1, Ernst Erb
