Labrador 472 Plan 019-241

Labrador 472 Plan 019-241; Grandin, Cristal- (ID = 1200355) Radio

Labrador 472 Plan 019-241; Grandin, Cristal- (ID = 1456212) Radio

Labrador 472 Plan 019-241; Grandin, Cristal- (ID = 1200356) Radio
Labrador 472 Plan 019-241; Grandin, Cristal- (ID = 1200357) Radio Labrador 472 Plan 019-241; Grandin, Cristal- (ID = 287499) Radio
Use red slider bar for more.
Labrador 472 Plan 019-241; Grandin, Cristal- (ID = 1200357) Radio
Grandin, Cristal-: Labrador 472 Plan 019-241 [Radio] ID = 1200357 700x530
Select picture or schematic to display from thumbnails on the right and click for download.
For model Labrador 472 Plan 019-241, Grandin, Cristal-Grandin (voir aussi ORA); Paris, Montreuil:
aus Servicedokumentation

Country:  France
Manufacturer / Brand:  Grandin, Cristal-Grandin (voir aussi ORA); Paris, Montreuil
Year: 1958 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH81 UBF89 UCL82 UY85
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: Labrador 472 Plan 019-241 - Grandin, Cristal-Grandin voir
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 250 x 160 x 120 mm / 9.8 x 6.3 x 4.7 inch
Notes

Voir aussi modèles identiques/similaires :

Net weight (2.2 lb = 1 kg) 1.7 kg / 3 lb 11.9 oz (3.744 lb)
Literature/Schematics (1) -- Schematic

Model page created by Peter Hoddow. See "Data change" for further contributors.



All listed radios etc. from Grandin, Cristal-Grandin (voir aussi ORA); Paris, Montreuil
Here you find 267 models, 197 with images and 78 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
