TK400 Automatic Uz

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Grundig Ltd., London

• Year
• 1965

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 70852

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• EF86 EF83 ECC81 ECL86

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 130; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 4 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: TK400 Automatic [Uz] - Grundig Ltd., London

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 12 x 11 x 7 inch / 305 x 279 x 178 mm

• Notes
• Dieses Gerät wurde in Belfast/Irland für den Export nach USA und Canada hergestellt.

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)

• External source of data
• Bedienungsanleitung

• Other Models

• Here you find 52 models, 41 with images and 26 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
