For model A2, Gunther Radio; Brussels:
Voransicht

Country:  Belgium
Manufacturer / Brand:  Gunther Radio; Brussels
Year: 1937 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6J8G 6K7G 6Q7G 6V6G ME6 5Z4G
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 140; 160; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 20 cm = 7.9 inch
Power out 5 W (unknown quality)
from Radiomuseum.org Model: A2 - Gunther Radio; Brussels
Material Wooden case, TUBES VISIBLE.
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 560 x 320 x 290 mm / 22 x 12.6 x 11.4 inch
Net weight (2.2 lb = 1 kg) 14.1 kg / 31 lb 0.9 oz (31.057 lb)

Model page created by Evert Vrieze. See "Data change" for further contributors.



All listed radios etc. from Gunther Radio; Brussels
Here you find 4 models, 4 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
