Civic Patrol S-94

Civic Patrol S-94; Hallicrafters, The; (ID = 562167) Amateur-R

Civic Patrol S-94; Hallicrafters, The; (ID = 562168) Amateur-R

Civic Patrol S-94; Hallicrafters, The; (ID = 562169) Amateur-R

Civic Patrol S-94; Hallicrafters, The; (ID = 562170) Amateur-R

Civic Patrol S-94; Hallicrafters, The; (ID = 562171) Amateur-R

Civic Patrol S-94; Hallicrafters, The; (ID = 562172) Amateur-R

Civic Patrol S-94; Hallicrafters, The; (ID = 2080910) Amateur-R
Civic Patrol S-94; Hallicrafters, The; (ID = 198140) Amateur-R Civic Patrol S-94; Hallicrafters, The; (ID = 198141) Amateur-R
Civic Patrol S-94; Hallicrafters, The; (ID = 198142) Amateur-R Civic Patrol S-94; Hallicrafters, The; (ID = 235905) Amateur-R
Civic Patrol S-94; Hallicrafters, The; (ID = 235906) Amateur-R Civic Patrol S-94; Hallicrafters, The; (ID = 562166) Amateur-R
Civic Patrol S-94; Hallicrafters, The; (ID = 1636707) Amateur-R Civic Patrol S-94; Hallicrafters, The; (ID = 1636708) Amateur-R
Civic Patrol S-94; Hallicrafters, The; (ID = 1666707) Amateur-R Civic Patrol S-94; Hallicrafters, The; (ID = 1672255) Amateur-R
Use red slider bar for more.
Civic Patrol S-94; Hallicrafters, The; (ID = 198140) Amateur-R
Hallicrafters, The;: Civic Patrol S-94 [Amateur-R] ID = 198140 550x304
Select picture or schematic to display from thumbnails on the right and click for download.
For model Civic Patrol S-94, Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX:
eBay seller: surfcaster43 (USA). #9706377485

Country:  United States of America (USA)
Manufacturer / Brand:  Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX
Year: 1955–1962 Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Valves / Tubes 8: 6BH6 12AT7 12BA6 12BA6 12AL5 12AU7 6BH6 50L6
Main principle Superhet with RF-stage; ZF/IF 10700 kHz; 2 AF stage(s)
Wave bands Short Wave (SW only)
Details
Power type and voltage AC/DC-set / 105-125 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: Civic Patrol S-94 - Hallicrafters, The; Chicago,
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 12.9 x 7 x 7.25 inch / 328 x 178 x 184 mm
Notes Coverage: 30-50MHz, updated version of the S-82
Price in first year of sale 60.00 $
Source of data Radios by hallicrafters
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date 3-56, Set 310, Folder 7)
Literature/Schematics (3) Sears, Roebuck Catalogs (Silvertone) (Fall/Winter 1960, page 1312. Fall/Winter 1961, page 1231.)
Literature/Schematics (4) Sears, Roebuck Catalogs (Silvertone) (Fall/Winter 1957, page 1006; order=57D 07494)
