Sky Buddy S-19R 2nd run

Sky Buddy S-19R; Hallicrafters, The; (ID = 1106194) Amateur-R

Sky Buddy S-19R; Hallicrafters, The; (ID = 1106195) Amateur-R
Sky Buddy S-19R; Hallicrafters, The; (ID = 1104899) Amateur-R Sky Buddy S-19R; Hallicrafters, The; (ID = 1104900) Amateur-R
Sky Buddy S-19R; Hallicrafters, The; (ID = 1104901) Amateur-R Sky Buddy S-19R; Hallicrafters, The; (ID = 1987428) Amateur-R
Use red slider bar for more.
Sky Buddy S-19R; Hallicrafters, The; (ID = 1104899) Amateur-R
Hallicrafters, The;: Sky Buddy S-19R [Amateur-R] ID = 1104899 614x461
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sky Buddy S-19R 2nd run, Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX

Country:  United States of America (USA)
Manufacturer / Brand:  Hallicrafters, The; Chicago, IL and Arlington/Grand Prairie, TX
Year: 1942 Category: Amateur-Receiver (amateur bands, may include broadcast bands)
Valves / Tubes 6: 6K8 6SK7 6SQ7GT 76 41 80
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Short Wave(s) and Police.
Details
Power type and voltage Line / Storage batteries (perhaps also batteries) / AC 115; Batt.6 (& 260) Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: Sky Buddy S-19R [2nd run] - Hallicrafters, The; Chicago,
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 17.5 x 8.5 x 8.5 inch / 445 x 216 x 216 mm
Notes Coverage 0.540-1.7, 1.7-5.5, 5.5-17, 16-46 MHz. Receives AM, CW (with BFO). DC operation possible with either two batteries (6V storage and 260 dry batt.), or a single 6 V storage battery and vibrapack.
Net weight (2.2 lb = 1 kg) 10.1 kg / 22 lb 3.9 oz (22.247 lb)
Mentioned in - - Manufacturers Literature

Model page created by Sinisa Trlin. See "Data change" for further contributors.
