Oscilloscope HM-303
HAMEG GmbH, Frankfurt
- Country
- Germany
- Manufacturer / Brand
- HAMEG GmbH, Frankfurt
- Year
- 1985 ??
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 150910
Bild aus ELV Katalog 1995
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- D14-364GY
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- - without
- Power type and voltage
- Alternating Current supply (AC) / 100-240 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Oscilloscope HM-303 - HAMEG GmbH, Frankfurt
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 285 x 125 x 380 mm / 11.2 x 4.9 x 15 inch
- Notes
- 30 MHz,
Vertikal: 2 Kanäle, max. 2mV/cm,
Zeitbasis: 0.5s-10ns/cm,
Triggerung bis 100 MHz,
Komponenten-Tester, 1KHz/1MHz Kalibrator.
- Net weight (2.2 lb = 1 kg)
- 6.3 kg / 13 lb 14 oz (13.877 lb)
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Dieter ADAM. See "Data change" for further contributors.
