Oscilloscope HM512-6

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673787) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673788) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673789) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673790) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673791) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673792) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673794) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673795) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673796) Equipment

Oscilloscope HM512-6; HAMEG GmbH, (ID = 673797) Equipment
Use red slider bar for more.
Oscilloscope HM512-6; HAMEG GmbH, (ID = 673787) Equipment
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  HAMEG GmbH, Frankfurt
Year: 1976 Category: Service- or Lab Equipment
Valves / Tubes 1: D13-650GH
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oscilloscope HM512-6 - HAMEG GmbH, Frankfurt
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 212 x 237 x 380 mm / 8.3 x 9.3 x 15 inch
Notes Hameg Two-Channel-Oscilloscope HM512-6.
0-40 MHz (-3 dB), overshoot max. 1 %, input impedace 1 MOhm/25 pF, linearity error max. 2 %, 12 kV on the CRT.
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Source of data -- Original-techn. papers.

Model page created by Sinisa Trlin. See "Data change" for further contributors.
