Oszillograph HM107/7

Oszillograph HM107/7; HAMEG GmbH, (ID = 1239652) Equipment

Oszillograph HM107/7; HAMEG GmbH, (ID = 1239653) Equipment

Oszillograph HM107/7; HAMEG GmbH, (ID = 1239654) Equipment

Oszillograph HM107/7; HAMEG GmbH, (ID = 1239655) Equipment

Oszillograph HM107/7; HAMEG GmbH, (ID = 1239656) Equipment
Oszillograph HM107/7; HAMEG GmbH, (ID = 333117) Equipment Oszillograph HM107/7; HAMEG GmbH, (ID = 904638) Equipment
Oszillograph HM107/7; HAMEG GmbH, (ID = 904639) Equipment
Use red slider bar for more.
Oszillograph HM107/7; HAMEG GmbH, (ID = 333117) Equipment
HAMEG GmbH,: Oszillograph HM107/7 [Equipment] ID = 333117 562x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oszillograph HM107/7, HAMEG GmbH, Frankfurt

Country:  Germany
Manufacturer / Brand:  HAMEG GmbH, Frankfurt
Year: 1969 ?? Category: Service- or Lab Equipment
Valves / Tubes 6: EC92 ECC88 ECC85 ECC85 EZ80 DG7-32
Semiconductors (the count is only for transistors) 4: BC107 BC107 BC107 BC107
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oszillograph HM107/7 - HAMEG GmbH, Frankfurt
Material Metal case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 162 x 205 x 240 mm / 6.4 x 8.1 x 9.4 inch
Notes Letzte Version der 107er-Reihe. Konv. Verdrahtung und gedruckte Platine. X-Freq. 10 HZ- 500 kHz oder ext. in 7 Schaltstufen und Feinregulierung (Vernier). Regler für X-Amplitude an der Frontplatte. Y-Eingang 1MOhm/ 40pF an BNC-Buchse; Maximale Eingangsempfindlichkeit von 50mV~/cm in 5 Schaltstufen abschwächbar, zusätzlicher 1:10 Schalter. Eingänge an der Frontplatte für X, Sync. und Z. Die Modellbezeichnung steht auf dem Netztrafo.
Net weight (2.2 lb = 1 kg) 5.3 kg / 11 lb 10.8 oz (11.674 lb)

Model page created by Otto Frosinn. See "Data change" for further contributors.
