For model Sinus-Generator HM8037, HAMEG GmbH, Frankfurt:
Low Distortion Generator HM8037

Country:  Germany
Manufacturer / Brand:  HAMEG GmbH, Frankfurt
Year: 1984 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Sinus-Generator HM8037 - HAMEG GmbH, Frankfurt
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 135 x 68 x 228 mm / 5.3 x 2.7 x 9 inch
Notes Hameg Modularsystem
Frequenzbereich 5 Hz bis 50 kHz
Klirrfaktor < 0,01 %
Digitale Frequenzanzeige
Ausgangsspannung > 1,5 V an 600 OHm
Nur im Grundgerät HM 8001 zu benutzen
Net weight (2.2 lb = 1 kg) 0.650 kg / 1 lb 6.9 oz (1.432 lb)
Source of data -- Original prospect or advert
