AVR-10

Harman Kardon; New York

Data
Forum
Pictures
Collections

  • Year
  • 1995 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 211486

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Details
  • Hi-Fi equipment
  • Power type and voltage
  • Alternating Current supply (AC) / 120 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: AVR-10 - Harman Kardon; New York
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 17.44 x 4.87 x 14.93 inch / 443 x 124 x 379 mm
  • Notes
  • Harman/Kardon AM/FM Stereo Receiver Model AVR-10.
    Stereo Mode: Continuous Average Power (FTC)35 Watts from 20Hz-20kHz: @<0.09% THD, both channels driven into 8 Ohms.
    Five Channel Surround Mode: Continuous average power per channel (FTC) Front L&R channels 30 Watts from 20Hz-20kHz: @<0.3% THD, both channels driven into 8 Ohms. Center channel 30 Watts at 1kHz: @<0.3% THD, driven into 8 Ohms Rear channels 20 Watts at 1kHz: @<1.0% THD, both channels driven into 8 Ohms.
    Made in Korea.
  • Net weight (2.2 lb = 1 kg)
  • 18 lb 0 oz (18 lb) / 8.172 kg
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
