HI-Current Capability Integrated Amplifier PM650
Harman Kardon; New York
- Country
- United States of America (USA)
- Manufacturer / Brand
- Harman Kardon; New York
- Year
- 1983/1984
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 269732
Q: Harman Kardon, Katalog 1983
Q: Harman Kardon, Katalog 1983
- Number of Transistors
- 85
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Details
- Hi-Fi equipment
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 100 W (200 W max.)
- Material
- Metal case
- from Radiomuseum.org
- Model: HI-Current Capability Integrated Amplifier PM650 - Harman Kardon; New York
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 440 x 130 x 403 mm / 17.3 x 5.1 x 15.9 inch
- Notes
-
RMS power output: 50W+50W at 0.08% T.H.D. (8 ohm)
Frequency response (-3 db): 0.5 Hz - 140 Khz
IM Distorsion: Less than 0.1%
Slew Rate: 100V/ msec.
Overall Negative Feedback: 15 db
S/N (IHF-A) Phono: 78 db - AUX: 80 db
Phono Overload MM more 220 mV at 1 Khz - MC more than 5 mV at 1 Khz
Semiconductors: 83 transistor, 2 Fets, 8 Diodes,17 Zener Diodes,3 Bridge Silicon Diodes, 2 Varistors.
Power consumption : 350W
- Net weight (2.2 lb = 1 kg)
- 11.8 kg / 25 lb 15.9 oz (25.991 lb)
- Price in first year of sale
- 1,498.00 DM
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
