JBL On Time Micro

JBL On Time Micro ; Harman Kardon; New (ID = 1886341) Radio JBL On Time Micro ; Harman Kardon; New (ID = 1886344) Radio
JBL On Time Micro ; Harman Kardon; New (ID = 1886345) Radio JBL On Time Micro ; Harman Kardon; New (ID = 1886346) Radio
JBL On Time Micro ; Harman Kardon; New (ID = 1886347) Radio JBL On Time Micro ; Harman Kardon; New (ID = 1886348) Radio
JBL On Time Micro ; Harman Kardon; New (ID = 1886349) Radio JBL On Time Micro ; Harman Kardon; New (ID = 1886350) Radio
JBL On Time Micro ; Harman Kardon; New (ID = 1886351) Radio JBL On Time Micro ; Harman Kardon; New (ID = 1886352) Radio
Use red slider bar for more.
JBL On Time Micro ; Harman Kardon; New (ID = 1886341) Radio
Harman Kardon; New: JBL On Time Micro [Radio] ID = 1886341 1400x1664
Select picture or schematic to display from thumbnails on the right and click for download.
For model JBL On Time Micro, Harman Kardon; New York:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  United States of America (USA)
Manufacturer / Brand:  Harman Kardon; New York
Year: 2008 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle PLL, Phase-locked loop
Wave bands Broadcast (BC) and FM or UHF.
Details HD or solid state memory; Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 240 Volt
Loudspeaker 2 Loudspeakers / Ø 4.5 cm = 1.8 inch
Power out 12 W (unknown quality)
from Radiomuseum.org Model: JBL On Time Micro - Harman Kardon; New York
Material Various materials
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 203 x 203 x 116 mm / 8 x 8 x 4.6 inch
Notes

70 Hz- 20kHz.

Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Mentioned in -- Original-techn. papers.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
