Five (5)

Five ; Harringtons Ltd; (ID = 1427247) Radio
Five ; Harringtons Ltd; (ID = 1426621) Radio Five ; Harringtons Ltd; (ID = 1426611) Radio
Five ; Harringtons Ltd; (ID = 1426614) Radio Five ; Harringtons Ltd; (ID = 1426616) Radio
Five ; Harringtons Ltd; (ID = 1426618) Radio Five ; Harringtons Ltd; (ID = 1426623) Radio
Five ; Harringtons Ltd; (ID = 1426624) Radio
Use red slider bar for more.
Five ; Harringtons Ltd; (ID = 1426621) Radio
Harringtons Ltd;: Five [Radio] ID = 1426621 933x548
Select picture or schematic to display from thumbnails on the right and click for download.
For model Five (5), Harringtons Ltd; Sydney:
Harringtons Five cabinet front view

Country:  Australia
Manufacturer / Brand:  Harringtons Ltd; Sydney
Year: 1927 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5:
Main principle TRF without regeneration; 2 AF stage(s); Neutrodyne
Tuned circuits 3 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Five - Harringtons Ltd; Sydney
Material Wooden case
Shape Tablemodel, slant panel.
Dimensions (WHD) 600 x 300 x 320 mm / 23.6 x 11.8 x 12.6 inch
Notes

Two dials (primary tuning controls). Trimmer tuning control , Tone control.



Price in first year of sale 35.00 Aus£

Model page created by Lindsay Shepherd. See "Data change" for further contributors.



All listed radios etc. from Harringtons Ltd; Sydney
Here you find 20 models, 20 with images and 1 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
