• Country
• United States of America (USA)

• Manufacturer / Brand
• Heathkit (Brand), Heath Co.; Benton Harbor (MI)

• Year
• 1976

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 127996

• • alternative name: Heath Company

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 105-128; 210-256 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Various materials

• from Radiomuseum.org
• Model: CRT Tester and Rejuvenator IT-5230 - Heathkit Brand, Heath Co.;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 343 x 130 x 254 mm / 13.5 x 5.1 x 10 inch

• Notes

• For Color CRTs.

  Sockets: 14-pin for 90 Grad color tubes, 13-pin for inline-gun color tubes, 8-pin for black and white tubes, 7-pin for black and white tubes.

  Heater Supply Voltage: Variable from 2 volts to 12 volts at 1 ampere.



• Net weight (2.2 lb = 1 kg)
• 3.5 kg / 7 lb 11.3 oz (7.709 lb)

• Price in first year of sale
• 498.00 DM

• Source of data
• -- Collector info (Sammler)

• Author
• Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
