• Year
  • 1968
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 89222
    • alternative name: Heath Company

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • FM Broadcast Band Only
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Various materials
  • from Radiomuseum.org
  • Model: FM Receiver AR-14 - Heathkit Brand, Heath Co.;
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 392 x 100 x 297 mm / 15.4 x 3.9 x 11.7 inch
  • Notes
  • Kombination des Stereo-Tuners AJ-14 und Stereo-Verstärkers AA-14 in einem Gehäuse aus Holz (AE-55) oder Metall (AE-65).
  • Net weight (2.2 lb = 1 kg)
  • 7 kg / 15 lb 6.7 oz (15.419 lb)
  • Price in first year of sale
  • 650.00 DM
  • Source of data
  • -- Original prospect or advert
  • Literature/Schematics (1)
  • -- Schematic
