Laboratory Oscilloscope O-12 (0-12)

Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 209510) Equipment

Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 209511) Equipment

Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 209512) Equipment

Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 209513) Equipment
Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 209509) Equipment Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 671207) Equipment
Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 716227) Equipment Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 932597) Equipment
Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 932598) Equipment Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 932599) Equipment
Use red slider bar for more.
Laboratory Oscilloscope O-12 ; Heathkit Brand, (ID = 209509) Equipment
Heathkit Brand,: Laboratory Oscilloscope O-12 [Equipment] ID = 209509 524x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Laboratory Oscilloscope O-12 (0-12), Heathkit (Brand), Heath Co.; Benton Harbor (MI)

Country:  United States of America (USA)
Manufacturer / Brand:  Heathkit (Brand), Heath Co.; Benton Harbor (MI)
alternative name

Heath Company
Year: 1959–1965 Category: Service- or Lab Equipment
Valves / Tubes 11: 6AB4 6AN8 12BH7 6J6 6C4 12AU7 12AU7 12AU7 6X4 1V2 5UP1
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Laboratory Oscilloscope O-12 - Heathkit Brand, Heath Co.;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 8.625 x 14.13 x 16 inch / 219 x 359 x 406 mm
Notes Breitband-Oszillograph für die gesamte Impuls-, Ton- und Fernsehtechnik, Y-Verstärker 3 Hz...5 MHz, X-Verstärker: 1 Hz...400 kHz, Kippteil: 10 Hz...500 kHz, Schirmdurchmesser: 130 mm, Preis für Bausatz: DM 599.- Bausatz; deutsche Ausführung für 110/220V Netzspannung
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 699.00 DM
Collectors' prices
Source of data -- Original-techn. papers.

Model page created by Hans-Dieter Haase † 5.2.18. See "Data change" for further contributors.



All listed radios etc. from Heathkit (Brand), Heath Co.; Benton Harbor (MI)
Here you find 659 models, 638 with images and 474 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
