Audio Generator IG-72E
Heathkit (Brand), Heath Co.; Benton Harbor (MI)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Heathkit (Brand), Heath Co.; Benton Harbor (MI)
- Year
- 1962–1977
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 80173
-
- alternative name: Heath Company
Bild aus Prospect 1971/72
FS1966 Heft 5 Seite 297
deutsche Anleitung , mit Umschlag 28 Seiten
2 Elkos gewechselt
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 110, 220 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Audio Generator IG-72E - Heathkit Brand, Heath Co.;
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 240 x 170 x 130 mm / 9.4 x 6.7 x 5.1 inch
- Notes
- RC Sinus Generator 10 Hz - 100 kHz. Suffix "E" for multivoltage model (European mains voltages). Otherwise similar to IG-72. Bausatz 275 DM, Fertiggerät 395 DM in D.
- Net weight (2.2 lb = 1 kg)
- 2.5 kg / 5 lb 8.1 oz (5.507 lb)
- Price in first year of sale
- 395.00 DM
- Mentioned in
- -- Original prospect or advert (deutscher Heathkit Katalog 1971/72)
- Author
- Model page created by Hinrich Grensemann † 15.5.16. See "Data change" for further contributors.
