HF-Linear-Amplifier SB-220

HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 126688) Amateur-D

HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 126689) Amateur-D
HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 767816) Amateur-D HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 173548) Amateur-D
HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 767818) Amateur-D HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 767820) Amateur-D
HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 173547) Amateur-D HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 767817) Amateur-D
HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 767819) Amateur-D HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 73520) Amateur-D
Use red slider bar for more.
HF-Linear-Amplifier SB-220; Heathkit Brand, (ID = 767816) Amateur-D
Heathkit Brand,: HF-Linear-Amplifier SB-220 [Amateur-D] ID = 767816 933x547
Select picture or schematic to display from thumbnails on the right and click for download.
For model HF-Linear-Amplifier SB-220, Heathkit (Brand), Heath Co.; Benton Harbor (MI):
Ebay 320530192671

Country:  United States of America (USA)
Manufacturer / Brand:  Heathkit (Brand), Heath Co.; Benton Harbor (MI)
alternative name

Heath Company
Year: 1970–1978 Category: Amateur Equipment (Other, but not Key)
Valves / Tubes 2: 3-500Z 3-500Z
Main principle Radio Frequency Amplification only
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 120; 240 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: HF-Linear-Amplifier SB-220 - Heathkit Brand, Heath Co.;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 380 x 210 x 370 mm / 15 x 8.3 x 14.6 inch
Notes Heathkit HF-Linear-Amplifier SB-220.
Grounded grid linear power amplifier for 80 to 10 meters HAM bands. Driver power ca. 100 W, Pout: abt. 1200 W.
Net weight (2.2 lb = 1 kg) 25 kg / 55 lb 1.1 oz (55.066 lb)
Price in first year of sale 370.00 USD
Source of data -- Original prospect or advert
Mentioned in Heathkit: A Guide to Amateur Radio Products

Model page created by a member from D. See "Data change" for further contributors.
