- Country
- Germany
- Manufacturer / Brand
- Heco, Hennel & Co. KG; Schmitten, Pulheim (auch Berlin)
- Year
- 1969 ?
- Category
- Loudspeaker, headphone or earphone
- Radiomuseum.org ID
- 247743
Heco Sales Brochure 1969
- Wave bands
- - without
- Power type and voltage
- No Power needed
- Loudspeaker
- 2 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: SE-69 - Heco, Hennel & Co. KG;
- Shape
- Book-shelf unit.
- Dimensions (WHD)
- 250 x 440 x 175 mm / 9.8 x 17.3 x 6.9 inch
- Notes
-
Heco geschlossener 2-Weg-Ecklautsprecher Modell SE-69.
70 - 16000 Hz, 10 Watt, 5 Ohm.
12,5 Liter Bruttovolumen
1x TT-System dyn. 175mm, 1x HT 100 mm
Nussbaumgehäuse.
- Net weight (2.2 lb = 1 kg)
- 3.3 kg / 7 lb 4.3 oz (7.269 lb)
- Price in first year of sale
- 98.00 DM
- Mentioned in
- -- Original prospect or advert
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
