1 GHZ Plug-In (Sampling) 1810A

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326047) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326048) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326049) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326050) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326051) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326052) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326053) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326054) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326055) Equipment

1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1326056) Equipment
1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1327427) Equipment 1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1325115) Equipment
1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1327430) Equipment
Use red slider bar for more.
1 GHZ Plug-In 1810A; Hewlett-Packard, HP; (ID = 1327427) Equipment
Hewlett-Packard, HP;: 1 GHZ Plug-In 1810A [Equipment] ID = 1327427 719x539
Select picture or schematic to display from thumbnails on the right and click for download.
For model 1 GHZ Plug-In (Sampling) 1810A, Hewlett-Packard, (HP); Palo Alto, CA:
Bemerkenswert: 2-Kanäle mit einer Bandbreite von DC bis 1GHZ

Country:  United States of America (USA)
Manufacturer / Brand:  Hewlett-Packard, (HP); Palo Alto, CA
Year: 1971 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 101:
Wave bands - without
Details
Power type and voltage Powered by external power supply or a main unit.
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: 1 GHZ Plug-In 1810A - Hewlett-Packard, HP; Palo Alto
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 195 x 123 x 345 mm / 7.7 x 4.8 x 13.6 inch
Notes

Der Einschub 1810A ergänzt die HP Oszilloskope der Serie 180 um zwei Sampling-Kanäle mit 1 GHz Bandbreite. Max. Input ist +-5 V DC/AC. Die Pulse Response liegt unter 350 ps.

Die Zeitbasis überstreicht die Bereiche 10 ns/div bis 50 µsec/div in 12 kalibrierten Positionen. Expansion bis x100 in 7 kalibrierten Stufen.

Net weight (2.2 lb = 1 kg) 3.2 kg / 7 lb 0.8 oz (7.048 lb)
Price in first year of sale 1'650.00 USD
Source of data - - Manufacturers Literature
Mentioned in Operating and Service Manual, 1GHz Plug-In (Sampling) 1810A, HP

Model page created by Thomas Wuwer. See "Data change" for further contributors.
