Wide Band Amplifiers 461A & 462A
Hewlett-Packard, (HP); Palo Alto, CA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Hewlett-Packard, (HP); Palo Alto, CA
- Year
- 1972 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 150698
front
back side
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Semiconductors
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 115; 230 Volt
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Wide Band Amplifiers 461A & 462A - Hewlett-Packard, HP; Palo Alto
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 130 x 60 x 300 mm / 5.1 x 2.4 x 11.8 inch
- Notes
-
The -hp- Models 461A and 462A Wide Band Amplifiers can faithfully amplify both sinusoidal and complex signals in the 1 kHz to 150 MHz range. The model 461A is best suited for sinusoidal inputs, and the Model 462A is designed for complex and pulse inputs.
Messverstärker, 1 kHz bis 150 MHz.
Verstärkung schaltbar 20 dB und 40 dB.
Ein- und Ausgang auf BNC-Anschlüssen, Impedanz 50 Ohm.
- Net weight (2.2 lb = 1 kg)
- 2 kg / 4 lb 6.5 oz (4.405 lb)
- Price in first year of sale
- 7,200.00 DM
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Johann Nussbaum. See "Data change" for further contributors.
