For model Digital Oscillator 4204A, Hewlett-Packard, (HP); Palo Alto, CA

Country:  United States of America (USA)
Manufacturer / Brand:  Hewlett-Packard, (HP); Palo Alto, CA
Year: 1968–1970 ? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 115; 230 Volt
Loudspeaker - For headphones or amp.
Power out 0.16 W (unknown quality)
from Radiomuseum.org Model: Digital Oscillator 4204A - Hewlett-Packard, HP; Palo Alto
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 16.75 x 5.25 x 11.25 inch / 425 x 133 x 286 mm
Notes Four knob digital selection of frequency from 10 Hz to 1 MHz in 4 ranges.
Output 10V into 600 ohms. Frequency flat with 3%.
Net weight (2.2 lb = 1 kg) 8.5 kg / 18 lb 11.6 oz (18.722 lb)
Price in first year of sale 695.00 $
Source of data - - Manufacturers Literature

Model page created by Roy Johnson. See "Data change" for further contributors.
