Digital Voltmeter 3440A

• Country
• United States of America (USA)

• Manufacturer / Brand
• Hewlett-Packard, (HP); Palo Alto, CA

• Year
• 1963

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 128769

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 115; 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Digital Voltmeter 3440A - Hewlett-Packard, HP; Palo Alto

• Shape
• Rack

• Dimensions (WHD)
• 425 x 132 x 284 mm / 16.7 x 5.2 x 11.2 inch

• Notes
• Digital-Voltmeter mit Nixieröhren-Anzeige, 4-stellig.
  Plug-in Option 3445A ermöglicht automatische Meßbereichswahl (Auto-Ranging).

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 1,160.00 $

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• HP Journal Vol. 15 No. 3, Nov. 1963

• Literature/Schematics (2)
• HP Katalog 1969

• Author
• Model page created by Sven Hoffmann. See "Data change" for further contributors.
