Digital Voltmeter 3455A

Digital Voltmeter 3455A; Hewlett-Packard, HP; (ID = 912889) Equipment
Digital Voltmeter 3455A; Hewlett-Packard, HP; (ID = 912884) Equipment Digital Voltmeter 3455A; Hewlett-Packard, HP; (ID = 912885) Equipment
Digital Voltmeter 3455A; Hewlett-Packard, HP; (ID = 587939) Equipment Digital Voltmeter 3455A; Hewlett-Packard, HP; (ID = 912886) Equipment
Digital Voltmeter 3455A; Hewlett-Packard, HP; (ID = 912887) Equipment
Use red slider bar for more.
Digital Voltmeter 3455A; Hewlett-Packard, HP; (ID = 912884) Equipment
Hewlett-Packard, HP;: Digital Voltmeter 3455A [Equipment] ID = 912884 930x326
Select picture or schematic to display from thumbnails on the right and click for download.
For model Digital Voltmeter 3455A, Hewlett-Packard, (HP); Palo Alto, CA

Country:  United States of America (USA)
Manufacturer / Brand:  Hewlett-Packard, (HP); Palo Alto, CA
Year: 1976 ? Category: Service- or Lab Equipment
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Digital Voltmeter 3455A - Hewlett-Packard, HP; Palo Alto
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 425 x 89 x 527 mm / 16.7 x 3.5 x 20.7 inch
Notes 5-1/2 or 6-1/2 digit autoranging AC/DC voltmeter; basic 0.001% DC accuracy. 0.1 to 1000 V f.s. DC; 1 V to 1000 V f.s. AC, true RMS value up to 1 MHz.
Two or four-wires resistance measurements.
Programmable math functions; GPIB interface.
Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)
Source of data -- Original-techn. papers.
Literature/Schematics (1) HP Operating and Service Manual

Model page created by Emilio Ciardiello. See "Data change" for further contributors.
