Frequency Comb Generator 8406A

Hewlett-Packard, (HP); Palo Alto, CA

  • Year
  • 1971
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 249384

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 115/230 Volt
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Frequency Comb Generator 8406A - Hewlett-Packard, HP; Palo Alto
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 130 x 155 x 279 mm / 5.1 x 6.1 x 11 inch
  • Notes
  • The Hp Model 8406A supplies a frequency comb with a selectable spectral line spacing of 1 Mc,10 Mc,100 Mc.The generated frequency comb is usable to at least 4 GHz.The output level is continuosly variable by a front panel control.Interpolation amplitude level is continuosly variable by a front panel control.

    The 8406A Frequency Comb generator is used to calibrate other instruments which display the frequency domain, usually spectrum analyzer.

  • Net weight (2.2 lb = 1 kg)
  • 2.7 kg / 5 lb 15.2 oz (5.947 lb)
  • Mentioned in
  • - - Manufacturers Literature
  • Author
  • Model page created by Antonio Marra. See "Data change" for further contributors.
