Funktionsgenerator 3312A

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972491) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972492) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972493) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972494) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972495) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972496) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972497) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972498) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972499) Equipment

Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 972500) Equipment
Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542349) Equipment Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542364) Equipment
Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542351) Equipment Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542288) Equipment
Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542289) Equipment Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542350) Equipment
Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542365) Equipment Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 816243) Equipment
Use red slider bar for more.
Funktionsgenerator 3312A; Hewlett-Packard, HP; (ID = 542349) Equipment
Hewlett-Packard, HP;: Funktionsgenerator 3312A [Equipment] ID = 542349 933x632
Select picture or schematic to display from thumbnails on the right and click for download.
For model Funktionsgenerator 3312A, Hewlett-Packard, (HP); Palo Alto, CA

Country:  United States of America (USA)
Manufacturer / Brand:  Hewlett-Packard, (HP); Palo Alto, CA
Year: 1974 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 100; 120; 220; 240 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: Funktionsgenerator 3312A - Hewlett-Packard, HP; Palo Alto
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 212 x 100 x 385 mm / 8.3 x 3.9 x 15.2 inch
Notes Merkmale des Hauptgenerators: Ausgangssignale: Sinus, Rechteck, Dreieck, Rampe und Impuls. Frequenzbereich von 0,1 Hz bis 13 MHz in 8 Dekaden. Variable Symmetrie: Einstellbar von 80:20 bis 20:80. Ausgang: Abschwächer 1:1, 10:1, 100:1, 1000:1 und über 10:1 kontinuierliche Regelung
Net weight (2.2 lb = 1 kg) 2.4 kg / 5 lb 4.6 oz (5.286 lb)
Source of data -- Original-techn. papers.

Model page created by Michael Mehnert. See "Data change" for further contributors.
