Oscilloscope 1205A

• Country
• United States of America (USA)

• Manufacturer / Brand
• Hewlett-Packard, (HP); Palo Alto, CA

• Year
• 1968

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 128595

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• 115/230 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: Oscilloscope 1205A - Hewlett-Packard, HP; Palo Alto

• Shape
• Tablemodel, high profile (upright - NOT Cathedral nor decorative).

• Dimensions (WHD)
• 211 x 298 x 475 mm / 8.3 x 11.7 x 18.7 inch

• Notes
• 5 Millivolt Variante des 1200 A/B.

• Net weight (2.2 lb = 1 kg)
• 11.4 kg / 25 lb 1.8 oz (25.11 lb)

• Price in first year of sale
• 1,400.00 $

• Source of data
• - - Data from my own collection

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Sven Hoffmann. See "Data change" for further contributors.
